Full Description

Covers the test procedures for enclosed low-voltage ac power circuit breakers as follows:

a) Stationary or drawout circuit breakers of two-, three-, or four-pole construction, with one or more rated maximum voltages of 635 V (600 for units incorporating fuses), 508 V, and 254 V for application on systems having nominal voltages of 600, 480, and 240 V.
b) Unfused or fused type circuit breakers.
c) Manually operated or power operated circuit breakers with or without electromechanical or solid-state trip devices.
d) Fused drawouts consisting of current-limiting fuses in a drawout assembly intended to be connected in series with a low-voltage ac power circuit breaker to form a non-integrally fused circuit breaker.

This document applies to both integrally and non-integrally fused circuit breakers.

Product Details

Published: 06/05/2012 Number of Pages: 37 File Size: 1 file , 400 KB Product Code(s): 100305, 100305
